Xrefs are where AutoCAD stops being a drafting program and starts being a shared-database program with all the joys that implies. Yeah, I'm good. Here's the stuff that actually bites people:
**Attach vs Overlay is not cosmetic.** Attach *nests through*: if your drawing gets xref'd into someone else's sheet, everything you attached comes along. Overlay stays local. Base plans, surveys, background grids from another consultant — Overlay, unless you specifically want them to propagate. Wrong answer here and you've shipped half the building inside a floor plan.
**Paths are the whole battle.** Full path breaks the second anyone moves a folder. Relative path works if you keep the folder structure intact and everyone in the office mounts the same drive. Before you send anything out the door: `ETRANSMIT` — it packages the host DWG with every xref, font, and plot style into a zip. Anyone who emails a bare DWG with xrefs to a client has, at some point, heard the words "I can only see the text."
**The one thing that will ruin your week: coordinate discipline.** Everyone draws from 0,0,0. If a surveyor hands you a drawing with geometry 40 million units from the origin, or drawn at an arbitrary origin, and you try to align it by eye — stop. Insert at 0,0,0, then if it lands wrong, the fix is aligning a known point to a known point (ALIGN, or move from base point), never eyeballing. And the "why is it 25.4x too big" thing is units — `INSERTUNITS` controls what happens on attach, `INSUNITS` is the drawing's own setting. mm into inches, exactly that ratio.
**Editing:** don't REFEDIT unless you're desperate. Editing in place is how nested xrefs and block-definition conflicts get mangled. Open the source file, edit, save, reload. Right-click the xref in the palette → Open Reference does the right thing.
**Layer thing everyone forgets:** xref layers live in your drawing too, named `sourcefile$0$wall`. You can freeze/off them here without touching the source, which is either wonderful or how you accidentally kill your boss's ceiling plan.
**Plotting:** if an xref won't plot, check (1) its layers aren't off/frozen in this drawing, (2) the viewport isn't frozen for it, (3) `XCLIPFRAME` isn't set to plot your clip boundary.
What's the actual situation — setting up a shared base plan, a drawing that arrives as a grey box, an xref your coworker can't see, or are you trying to bind one before someone notices you used it?
